Digital Glass Body pH Electrode with Matching Pin for General Purpose — main photograph
Hanna InstrumentsAvailability: Supplied to order

Digital Glass Body pH Electrode with Matching Pin for General Purpose

Reference HI11311

The HI11311 electrode features a built-in microchip that stores sensor type, serial number, and calibration information. It also features a single ceramic junction and the spherical pH sensing portion is made with high temperature glass. This design consideration is ideal for general purpose laboratory use. This probe features a 3.5 mm connector designed exclusively to be used with Hanna Instruments edge® Tablet Meters .

Order this item

Nothing is charged online. Every request is reviewed by an AxiTech engineer before you receive a quotation.

At a glance

Reference
HI11311
Category
pH, Conductivity & Water Analysis
Equipment family
Industry/Industrial, Industry/Water, Industry/Industrial/Plating, Industry/Laboratory, Industry/Laboratory/Research, Industry/Food, Industry/Beverage, Industry/Laboratory/Education, Parameters/P - Z/p

Overview

The HI11311 electrode features a built-in microchip that stores sensor type, serial number, and calibration information. It also features a single ceramic junction and the spherical pH sensing portion is made with high temperature glass. This design consideration is ideal for general purpose laboratory use. This probe features a 3.5 mm connector designed exclusively to be used with Hanna Instruments edge® Tablet Meters .

Maintenance contract — AxiTech provides planned preventive maintenance for Digital Glass Body pH Electrode with Matching Pin for General Purpose from Hanna Instruments: scheduled visits, safety checks, periodic calibration and a documented service report, backed by a contractual response time.

Troubleshooting, repair and spare parts — our ph, conductivity & water analysis engineers diagnose and repair Digital Glass Body pH Electrode with Matching Pin for General Purpose on site or in the workshop, fit genuine spare parts and recommission the equipment after performance verification.

Features

  • Matching Pin
  • Double Junction Reference
  • 3.5 mm Connector

Technical specifications

Specifications
SKU
HI11311 Description refillable, combination, digital pH electrode w/ Sensor Check™ Reference double, Ag/AgCl Junction / Flow Rate ceramic, single / 15-20 µL/h Electrolyte KCl 3.5M Max Pressure 0.1 bar Range pH: 0 to 14 Recommended Operating Temperature -5 to 100°C (23 to 212°F) - HT Tip / Shape spheric (dia: 9.5 mm) Temperature Sensor yes Matching Pin yes Amplifier yes Body Material glass Cable 1 m (3.3') Recommended Use laboratory general purpose, beer Connection 3.5 mm connector
Cable
1 m (3.3') Recommended Use laboratory general purpose, beer Connection 3.5 mm connector
Range
pH: 0 to 14 Recommended Operating Temperature -5 to 100°C (23 to 212°F) - HT Tip / Shape spheric (dia: 9.5 mm) Temperature Sensor yes Matching Pin yes Amplifier yes Body Material glass Cable 1 m (3.3') Recommended Use laboratory general purpose, beer Connection 3.5 mm connector
Amplifier
yes Body Material glass Cable 1 m (3.3') Recommended Use laboratory general purpose, beer Connection 3.5 mm connector
Reference
double, Ag/AgCl Junction / Flow Rate ceramic, single / 15-20 µL/h Electrolyte KCl 3.5M Max Pressure 0.1 bar Range pH: 0 to 14 Recommended Operating Temperature -5 to 100°C (23 to 212°F) - HT Tip / Shape spheric (dia: 9.5 mm) Temperature Sensor yes Matching Pin yes Amplifier yes Body Material glass Cable 1 m (3.3') Recommended Use laboratory general purpose, beer Connection 3.5 mm connector
Connection
3.5 mm connector
Description
refillable, combination, digital pH electrode w/ Sensor Check™ Reference double, Ag/AgCl Junction / Flow Rate ceramic, single / 15-20 µL/h Electrolyte KCl 3.5M Max Pressure 0.1 bar Range pH: 0 to 14 Recommended Operating Temperature -5 to 100°C (23 to 212°F) - HT Tip / Shape spheric (dia: 9.5 mm) Temperature Sensor yes Matching Pin yes Amplifier yes Body Material glass Cable 1 m (3.3') Recommended Use laboratory general purpose, beer Connection 3.5 mm connector
Electrolyte
KCl 3.5M Max Pressure 0.1 bar Range pH: 0 to 14 Recommended Operating Temperature -5 to 100°C (23 to 212°F) - HT Tip / Shape spheric (dia: 9.5 mm) Temperature Sensor yes Matching Pin yes Amplifier yes Body Material glass Cable 1 m (3.3') Recommended Use laboratory general purpose, beer Connection 3.5 mm connector
Tip / Shape
spheric (dia: 9.5 mm) Temperature Sensor yes Matching Pin yes Amplifier yes Body Material glass Cable 1 m (3.3') Recommended Use laboratory general purpose, beer Connection 3.5 mm connector
Matching Pin
yes Amplifier yes Body Material glass Cable 1 m (3.3') Recommended Use laboratory general purpose, beer Connection 3.5 mm connector
Max Pressure
0.1 bar Range pH: 0 to 14 Recommended Operating Temperature -5 to 100°C (23 to 212°F) - HT Tip / Shape spheric (dia: 9.5 mm) Temperature Sensor yes Matching Pin yes Amplifier yes Body Material glass Cable 1 m (3.3') Recommended Use laboratory general purpose, beer Connection 3.5 mm connector
Body Material
glass Cable 1 m (3.3') Recommended Use laboratory general purpose, beer Connection 3.5 mm connector
Recommended Use
laboratory general purpose, beer Connection 3.5 mm connector
Temperature Sensor
yes Matching Pin yes Amplifier yes Body Material glass Cable 1 m (3.3') Recommended Use laboratory general purpose, beer Connection 3.5 mm connector
Junction / Flow Rate
ceramic, single / 15-20 µL/h Electrolyte KCl 3.5M Max Pressure 0.1 bar Range pH: 0 to 14 Recommended Operating Temperature -5 to 100°C (23 to 212°F) - HT Tip / Shape spheric (dia: 9.5 mm) Temperature Sensor yes Matching Pin yes Amplifier yes Body Material glass Cable 1 m (3.3') Recommended Use laboratory general purpose, beer Connection 3.5 mm connector
Recommended Operating Temperature
-5 to 100°C (23 to 212°F) - HT Tip / Shape spheric (dia: 9.5 mm) Temperature Sensor yes Matching Pin yes Amplifier yes Body Material glass Cable 1 m (3.3') Recommended Use laboratory general purpose, beer Connection 3.5 mm connector
Supply and reordering

AxiTech supplies Digital Glass Body pH Electrode with Matching Pin for General Purpose as a spare, so a worn part is replaced during the same visit rather than becoming a second call-out.

Ordering Digital Glass Body pH Electrode with Matching Pin for General Purpose

Tell us the reference, or the model and serial number of the instrument it belongs to, and we confirm the correct part, its price and its lead time. Parts ordered against a maintenance contract are carried on the visit.

  • Compatibility confirmed against your instrument before despatch
  • Quoted with a lead time, not just a price
  • Scheduled with your maintenance visit when you hold a contract
  • Standing orders for items you consume on a predictable cycle

The instrument it belongs to

AxiTech maintains, calibrates and repairs the Hanna Instruments instruments that Digital Glass Body pH Electrode with Matching Pin for General Purpose is used with. If you operate one, we can put it under a preventive maintenance contract and supply this item as part of the schedule.

Discover our maintenance contractsBrowse the equipment catalogue

Questions we are asked

Frequently asked questions about Hanna Instruments Digital Glass Body pH Electrode with Matching Pin for General Purpose

Yes. AxiTech supplies Digital Glass Body pH Electrode with Matching Pin for General Purpose to hospitals, clinics and laboratories, either as a one-off order or on a standing schedule. Send us the reference and the quantity and we come back with a price and a lead time.
