CBC 5 control — main photograph
IKAAvailability: Supplied to order

CBC 5 control

Reference 0004167000

CBC 5 control laboratory stirrer from IKA. AxiTech covers the full lifecycle: installation and commissioning, planned preventive maintenance, periodic calibration, on-site troubleshooting, workshop repair and spare parts supply.

Request a service for this equipment

Nothing is charged online. Every request is reviewed by an AxiTech engineer before you receive a quotation.

At a glance

Reference
0004167000
Category
Shakers, Stirrers & Mixers

Overview

CBC 5 control The CBC 5 control is a powerful refrigerated and heating circulator with strong heating and cooling power for an operating temperature range of - 25 °C to + 200 °C. It is best suited for external applications thanks to its proven pressure and suction pump. High-quality insulation of the device allows for fast heat-up times and reduces heat input at low temperatures. All parameters are manageable (read out, monitored and completely documented) by software (e. g., labworldsoft(r) or NAMUR commands). High performance pressure/suction pump (speed-controlled) Industry standard TFT display for maximum visibility (pump speed, temperature) Adjustable safety circuit Visible and audible alarm Safety drain valve USB / RS 232 interfaces (labworldsoft(r) and enabling online updates of device software) Connection for external temperature probe (PT 100) and optional external solenoid valves (multi-IO port) Safety classification III (FL, DIN 12876) Removable WiCo (wireless controller) enables safe remote operation, e.g. outside of a closed fume hood Scope of delivery CBC 5 control Hose olive NW 12 (2 pcs.) Screwdriver OS 1.0 power supply (for WiCo) USB Cable - USB A to Micro-B, 2 m U

Maintenance contract — AxiTech provides planned preventive maintenance for CBC 5 control from IKA: scheduled visits, safety checks, periodic calibration and a documented service report, backed by a contractual response time.

Troubleshooting, repair and spare parts — our shakers, stirrers & mixers engineers diagnose and repair CBC 5 control on site or in the workshop, fit genuine spare parts and recommission the equipment after performance verification.

Features

  • High performance pressure/suction pump (speed-controlled)
  • Industry standard TFT display for maximum visibility (pump speed, temperature)
  • Adjustable safety circuit
  • Visible and audible alarm
  • Safety drain valve
  • USB / RS 232 interfaces (labworldsoft(r) and enabling online updates of device software)
  • Connection for external temperature probe (PT 100) and optional external solenoid valves (multi-IO port)
  • Safety classification III (FL, DIN 12876)
  • Removable WiCo (wireless controller) enables safe remote operation, e.g. outside of a closed fume hood Scope of delivery CBC 5 control Hose olive NW 12 (2 pcs.) Screwdriver OS 1.0 power supply (for WiCo) USB Cable - USB A to Micro-B, 2 m USB 2.0 cable Micro A – Micro B
  • CBC 5 control
  • Hose olive NW 12 (2 pcs.)
  • Screwdriver
  • OS 1.0 power supply (for WiCo)
  • USB Cable - USB A to Micro-B, 2 m
  • USB 2.0 cable Micro A – Micro B

Technical specifications

Specifications
Weight
46.5 kg
Voltage
230 V
Frequency
50/60 Hz
Pump type
Pressure- / suction pump
Heat output
2500 W
Noise level
55 dB(A)
Power input
3000 W
Cooling agent
R134a
Standby input
5 VDC
USB interface
Micro-USB
Appliance type
Circulation thermostat
Battery Weight
55 / 3 g
Filling volume
5 - 7 l
Bath depth min.
150 mm
Battery Voltage
3.7 / 3 V
Multi Interface
yes
Pump connection
M16x1
RS 232 interface
yes
Battery Cell Type
custom LiPo/ CR2032
Calibration option
yes
Display resolution
0.01 K
Width bath opening
82 mm
Number of Batteries
2
Temperature control
PID
Temperature display
yes
Working temperature
-25 - 200 °C
Sub level protection
yes
Height including bath
172 mm
Solenoid valve output
24 VDC
Battery Energy Content
7.4 / 0.69 Wh
Cooling agent quantity
250 g
Dimensions (W x H x D)
275 x 690 x 490 mm
Cooling capacity (@0°C)
270 W
Pump capacity adjustable
yes
Warning function optical
yes
Adjustable safety circuit
0 - 260 °C
Cooling capacity (@10°C)
320 W
Cooling capacity (@20°C)
350 W
Safety temperature sensor
PT1000
Warning function acoustic
yes
Cooling capacity (@ 10°C)
190 W
Cooling capacity (@ 20°C)
80 W
Operating temperature min.
-25 °C
Safety temperature display
TFT
Solenoid valve output max.
0.8 A
Working temperature sensor
PT 100
Cooling agent pressure max.
20 bar
How is the Battery packaged
within appliance
Working temperature display
TFT
Permissible relative humidity
80 %
Permissible ambient temperature
5 - 32 °C
Class designation acc. DIN 12876
III
Warning function excess temperature
yes
Batteries included with the product?
yes
Cooling capacity (@ 20°C; 3200 rpm)
400 W
Flow rate max. (0 bar back pressure)
31 l/min
Cooling capacity (@ 20°C; 3200 rpm)
130 W
Identification according to DIN 12876
FL
Connection for ext. temperature sensor
PT 100
Display for operation with ext. sensor
yes
Technical data complies with the standard
DIN 12876
Temperature stability DIN 12876 (@+70°C)
±0.01 K
Warning function insufficient temperature
yes
Alarm output (potential free contact) max.
1 A
Protection class according to DIN EN 60529
IP 21
Pressure pump (suction side) (0 liter flow)
0.45 bar
Pump pressure max. (0 liters discharge flow)
0.61 bar
Service coverage

AxiTech maintains, repairs and supplies this equipment for hospitals, clinics, laboratories and imaging centres.

Maintenance contracts for CBC 5 control

AxiTech provides preventive maintenance contracts for CBC 5 control. Each contract fixes a schedule of planned visits in which our biomedical engineers inspect the equipment, replace wear parts before they fail, and verify that it still performs inside the manufacturer’s tolerances.

Every visit includes calibration and performance verification, and closes with a documented maintenance report you can present during an accreditation audit. Spare-parts availability and a guaranteed response time are written into the contract, so a breakdown never leaves a department waiting for an answer.

Plan at least one preventive maintenance visit per year, and a second visit for equipment in continuous or critical use.

  • Planned preventive maintenance visits at a fixed interval
  • Calibration and performance verification against the manufacturer’s specifications
  • A documented maintenance report after every intervention
  • Guaranteed availability of spare parts and consumables
  • A contractual response time when the equipment fails

Discover our maintenance contracts

Planned preventive maintenance and calibration under contract

Troubleshooting and repair for CBC 5 control

When CBC 5 control fails, our engineers start with a structured diagnostic: error codes, electrical and mechanical checks, and a functional test against the equipment’s own specification. That tells us whether the fault is a consumable, a worn part or a board-level failure before any part is ordered.

Straightforward faults are repaired on site so the department loses as little time as possible. Anything that needs a workbench, a full strip-down or a specialised spare part goes to our workshop and comes back only after a complete post-repair test and, where the equipment requires it, recalibration.

Faults we see most often on this type of equipment

The faults we see most often are worn moving parts, power-supply and control-board failures, sensors that have drifted out of tolerance, and fluid or air paths that have become blocked or contaminated.

Discover our troubleshooting and repair service

Diagnostics, corrective repair and spare parts in the workshop
Troubleshooting

How to troubleshoot CBC 5 control

Work through these checks before you escalate. They are the same first-line sequence our biomedical engineers run on arrival, and they either clear the fault or narrow it down enough that the intervention starts with the right spare part in the van.

  1. Capture the fault before you touch anything: write down the exact error code or message, the serial number from the rating plate, what the operator was doing and whether the fault clears on a restart.

  2. Confirm the power supply end to end — wall outlet, mains lead, fuse and any UPS or stabiliser in between. A device that is intermittently dead has a supply fault far more often than an internal one.

  3. Check the consumables and wear parts — filters, seals, tubing, probes, batteries — and note when each was last replaced. Anything past its service interval is the first suspect.

  4. Reproduce the fault once, deliberately, and record the sequence: what the operator did, what the device displayed, and whether a full power cycle clears it.

  5. If the fault is still there, escalate with the evidence. Send AxiTech the model, serial number, error code and the checks you have already run, and an engineer will come back with a diagnosis, a repair quote and a spare-parts lead time for CBC 5 control.

What to send us when you report the fault

  • Manufacturer, model and serial number, from the rating plate
  • The exact error code or message, and the screen it appears on
  • When the fault started, how often it occurs and what triggers it
  • A photograph of the display or of the fault, and the last maintenance report

If the fault survives all five steps, stop using CBC 5 control and open a repair request. Continuing to run equipment through a fault it cannot clear turns a component failure into a board-level one, and on devices used for diagnosis or therapy it puts the result — and the patient — in doubt.

Discover our troubleshooting and repair service

Buying and installing CBC 5 control

AxiTech supplies CBC 5 control together with the accessories and consumables it needs to enter service. We handle importation, delivery and installation, then commission the equipment on site so that it is verified against its specification before the first patient or the first sample.

Installation is followed by training for the users and for your biomedical team, warranty registration, and — if you want it — a maintenance contract that takes over the day the warranty ends, so the equipment never spends a period without planned service.

Discover our equipment sales service

Delivery, installation, commissioning and user training
Questions we are asked

Frequently asked questions about IKA CBC 5 control

Yes. AxiTech services CBC 5 control, either under a maintenance contract or as a one-off intervention. Our biomedical engineers cover preventive maintenance, calibration, corrective repair and spare-parts supply for this equipment.
